FortiGate® 7000E Series
Base price
Description
The FortiGate 7000E series delivers high performance next generation firewall (NGFW) capabilities for large enterprises and service providers. With multiple high-speed interfaces, high-port density, and high-throughput, ideal deployments are at the enterprise edge, hybrid data center core, and across internal segments. Leverage industry-leading IPS, SSL inspection, and advanced threat protection to optimize your network’s performance. Fortinet’s Security- Driven Networking approach provides tight network integration to the new security generation.
|
FORTIGATE |
7060E-8 / 7060E-9-(DC)* |
7040E-8 / 7040E-9-(DC) |
7030E |
|
Hardware Specifications |
|||
|
Fortinet Processor Module (FPM) Slots |
4 |
2 |
2 |
|
Fortinet Interface Module (FIM) Slots |
2 |
2 |
1 |
|
Shelf Manager |
2 |
1 |
1 |
|
System Performance and Capacity |
|||
|
Firewall Throughput (1518 / 512 / 64 byte, UDP) |
630 / 630 / 340 Gbps |
315 / 310 / 200 Gbps |
155 / 155 / 155 Gbps |
|
Firewall Latency (64 byte, UDP) |
7.00 μs |
7.00 μs |
7.00 μs |
|
Firewall Throughput (Packet per Second) |
510 Mpps |
300 Mpps |
220 Mpps |
|
Concurrent Sessions (TCP) |
320 Million |
160 Million |
160 Million |
|
New Sessions/Sec (TCP) |
1.8 Million |
950 000 |
900 000 |
|
Firewall Policies |
200 000 |
200 000 |
200 000 |
|
IPsec VPN Throughput (512 byte) |
100 Gbps |
100 Gbps |
40 Gbps |
|
Gateway-to-Gateway IPsec VPN Tunnels |
16 000 |
16 000 |
16 000 |
|
Client-to-Gateway IPsec VPN Tunnels |
64 000 |
64 000 |
64 000 |
|
SSL-VPN Throughput |
15 Gbps |
15 Gbps |
15 Gbps |
|
Concurrent SSL-VPN Users (Recommended Maximum) |
48 000 |
48 000 |
48 000 |
|
IPS Throughput (Enterprise Mix) 1 |
120 / 200 Gbps |
60 / 100 Gbps |
60 Gbps |
|
SSL Inspection Throughput 2 |
79.9 / 120 Gbps |
39.9 / 60 Gbps |
39.9 Gbps |
|
SSL Inspection CPS (IPS, avg. HTTPS) 3 |
47 000 |
32 500 |
32 500 |
|
SSL Inspection Concurrent Session (IPS, avg. HTTPS) 3 |
24 Million |
12 Million |
12 Million |
|
Application Control Throughput 3 |
160 Gbps |
80 Gbps |
65 Gbps |
|
NGFW Throughput 4 |
100 / 120 Gbps |
50 / 60 Gbps |
50 Gbps |
|
Threat Protection Throughput 5 |
80 / 96 Gbps |
40 / 48 Gbps |
35 Gbps |
|
CAPWAP Throughput |
N/A |
N/A |
N/A |
|
Virtual Domains (Default / Maximum) |
10 / 500 |
10 / 500 |
10 / 500 |
|
Maximum Number of FortiSwitches Supported |
256 |
256 |
256 |
|
Maximum Number of FortiAPs (Total / Tunnel Mode) |
N/A |
N/A |
N/A |
|
High Availability Configurations |
Active-Active (FGSP), Active- Passive, Clustering |
Active-Active (FGSP), Active- Passive, Clustering |
Active-Active (FGSP), Active- Passive, Clustering |
|
Dimensions |
|||
|
Height x Width x Length (inches) |
14.0 x 17.3 x 25.6 |
10.5 x 17.3 x 25.6 |
10.5 x 17.3 x 25.6 |
|
Height x Width x Length (mm) |
355.6 x 440 x 651 |
266.7 x 440 x 650 |
266.7 x 440 x 650 |
|
Weight |
210.2 lbs (95.4 kg) |
153.3 lbs (69.6 kg) |
134.9 lbs (61.3 kg) |
|
Form Factor (supports EIA/non-EIA standards) |
8 RU |
6 RU |
6 RU |
|
Power and Environment |
|||
|
Power Required |
AC (configured with 4 PSUs in a 3+1 redundant configuration, an additional 2 PSUs can be added for additional redundancy) |
AC (configured with 3 PSUs in a 2+1 redundant configuration, an additional PSU can be added for additional redundancy) |
AC (configured with 3 PSUs in a 2+1 redundant configuration, an additional PSU can be added for additional redundancy) |
|
Power Consumption (Maximum / Average) ** |
3277 / 2330 W |
2500 / 1800 W |
1940 / 1390 W |
|
AC Current (Maximum) |
12A@100V, 10A@240V |
12A@100V, 10A@240V |
12A@100V, 10A@240V |
|
Heat Dissipation (Maximum) ** |
11 184 BTU/h |
8530 BTU/h |
6619 BTU/h |
|
DC Power Supply |
-48V DC |
-48V DC |
– |
|
DC Current (Maximum) |
30A per feed (3+3) |
30A per feed (2+2) |
– |
|
Operating Temperature |
32°–104°F (0°–40°C) |
32°–104°F (0°–40°C) |
32°–104°F (0°–40°C) |
|
Storage Temperature |
-31°–158°F (-35°–70°C) |
-31°–158°F (-35°–70°C) |
-31°–158°F (-35°–70°C) |
|
Humidity |
20%–90% non-condensing |
20%–90% non-condensing |
20%–90% non-condensing |
|
Compliance |
|||
|
Certifications |
FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB |
FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB |
FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB |
